Diversitech DIVE-6274 Insulated Spade Terminals 16-14 Awg

Product Description

The DIVERSITECH DIVE-6274 is a pack of 22 insulated spade terminals designed for making secure, crimp-style electrical connections without soldering. Each terminal accepts 16-14 AWG wire and fits a No. 6 stud, making it a practical stock item for HVAC technicians, electricians, and control panel builders. The insulated barrel protects the crimp joint and reduces the risk of accidental contact in tight wiring spaces. These spade connectors are intended for use wherever a reliable, vibration-resistant mechanical connection to a screw terminal or bus bar is required.

Insulated spade terminals in the 16-14 AWG range are commonly used in low-voltage control wiring, HVAC equipment panels, electrical enclosures, and light commercial control systems. The No. 6 stud size suits standard terminal screws found on contactors, relays, terminal strips, and control boards. The crimp-on design speeds up termination work and eliminates the need for solder, flux, or heat, which is an advantage in the field or on the bench. A pack of 22 provides enough quantity for a typical service call or panel job without excess.

Key Features

• Insulated barrel provides electrical protection at the crimp joint
• Crimp termination eliminates the need for soldering
• Wire range 16-14 AWG accommodates common control and power wiring gauges
• No. 6 stud size fits standard terminal screws on relays, contactors, and terminal strips
• Pack of 22 terminals suits single-job or service-kit stocking
• Compact spade profile allows use in tight or crowded enclosures

Compatibility

Designed as a general-purpose insulated spade terminal for use with 16-14 AWG conductors and No. 6 mounting studs in HVAC control panels, electrical enclosures, and light commercial equipment.

Installation Notes

Installation should be performed by a qualified electrician or HVAC technician. De-energize the circuit and confirm zero voltage before making or breaking any terminal connections. Use a calibrated ratcheting crimp tool rated for insulated terminals to ensure a gas-tight crimp; an undersized or improper crimp tool can result in a high-resistance joint or pull-out failure. Verify wire gauge and stud size match before crimping, as mixing gauges with the wrong terminal barrel reduces connection integrity.

Technical Specifications

• Wire Range: 16-14 AWG
• Stud Size: No. 6
• Terminal Type: Insulated Spade
• Termination Method: Crimp
• Pack Quantity: 22 terminals

Standard Information

• Brand: DIVERSITECH
• Manufacturer Part Number: DIVE-6274
