Diversitech DDS-60SW Disconnect, MCS 60A 240VAC

Product Description

The DiversiTech DDS-60SW is a Molded Case Switch Disconnect, rated for 60A and 240VAC. This single-phase unit is designed for outdoor applications, featuring a NEMA 3R rated metallic enclosure. It eliminates the traditional pullout handle, offering a rugged and easy-to-use design for electrical circuit isolation in HVAC/R and other electrical distribution systems.

• Eliminates the pullout handle found in traditional AC disconnects for easier installation.
• Rated for 60A and 240VAC, suitable for single-phase, two-wire or split-phase, three-wire systems.
• Features a NEMA 3R rated metallic enclosure for outdoor applications, providing rain and sleet resistance.

Product Highlights

Rugged, easy-to-use molded case switch disconnect, UL listed and rated for outdoor applications.

Product Information

Standard Information

• Brand: DIVERSITECH
• Manufacturer Part Number: DDS-60SW
• Country of Origin: China

Technical Specifications

• Manufacturer: DiversiTech
• Device Type: Disconnect
• Series: MCS
• Amperage: 60A
• Voltage: 240VAC
• Phase: Single-phase
• NEMA Rating: 3R
• Type: Non-Fused
• Application: HVAC/R
• cUL Listed: Yes
• UL Listed: Yes
• Disconnect Mechanism: Switch
• No. of Fuses: 0
• Top or Side Open: Side
• UL Listed Number: IRF9
• US Patent: 6,630,637
