Diversitech ct101wa Smart Thermostat Central Hvac

Product Description

The DIVERSITECH ct101wa is a WiFi-enabled, ENERGY STAR certified smart thermostat designed for central ducted HVAC systems in residential and light commercial applications. It features a 3.5 square inch touch LCD and is hardwired at 24 volts for reliable power. The ct101wa supports multi-stage operation — up to 4 heat and 2 cool stages for heat pumps, and 2 heat and 2 cool stages for conventional systems — making it suitable for a wide range of system configurations. Licensed HVAC technicians install this thermostat as a direct control interface for central heating and cooling equipment. Keypad lockout, auto changeover, and cooling fan delay are included in the advanced feature set.

The ct101wa is compatible with conventional ducted HVAC systems including gas, oil, and electric furnaces, heat pumps with or without auxiliary heat, dual fuel systems, hot water systems, and geothermal setups. It is suited for residential new construction and retrofit installations where smart home integration is required. Scheduling flexibility supports 7-day, 5-1-1, and non-programmable modes. The WiFi programming interface allows remote access and schedule management. IAQ features include humidity control and an IAQ fan mode for indoor air quality management.

Key Features

• ENERGY STAR certified WiFi smart thermostat with 3.5 square inch touch LCD
• Hardwire power supply at 24 volts — no battery dependency
• Multi-stage support: 4 Heat/2 Cool for heat pumps, 2 Heat/2 Cool for conventional systems
• Compatible with gas, oil, electric furnace, heat pump with or without auxiliary, and dual fuel systems
• Advanced features include keypad lockout, auto changeover, cooling fan delay, and minimum compressor run-time
• IAQ fan mode and humidity control for indoor air quality management
• Flexible scheduling: 7-day, 5-1-1, and non-programmable options

Compatibility

Designed for conventional ducted HVAC systems including gas and oil furnaces, electric furnaces, heat pumps with auxiliary heat, heat pumps without auxiliary heat, dual fuel systems, hot water systems, and geothermal setups. Hardwire installation at 24 volts is required.

Installation Notes

Installation must be performed by a licensed HVAC technician in accordance with local codes and the equipment manufacturer's instructions. Always shut off power to the HVAC system at the breaker before removing the existing thermostat or making any wiring connections. This thermostat requires a hardwired 24-volt common (C-wire) connection — confirm C-wire availability before installation. WiFi network configuration is completed after physical installation through the device interface or a companion app.

Technical Specifications

• Certification: ENERGY STAR Certified
• Power Supply: Hardwire Only, 24 volts
• Stages: 4 Heat/2 Cool (Heat Pump), 2 Heat/2 Cool (Conventional)
• Display: 3.5 square inch Touch LCD
• Programming Interface: WiFi
• Scheduling: 7-Day, 5-1-1, Non-Programmable
• IAQ Features: Humidity Control, IAQ Fan Mode
• Advanced Features: Keypad Lockout, Auto Changeover, Cooling Fan Delay, Minimum Compressor Run-Time
• Product Height: 3.9 inches
• Product Width: 3.9 inches
• Product Length: 0.9 inches
• BABA Compliant: No

Standard Information

• Brand: DIVERSITECH
• Manufacturer Part Number: ct101wa
