Diversitech 97701 Packard ECM 230V evaporator fan motor 1/15 hp replaces 25317701S

Product Description

The DIVERSITECH 97701 is an ECM evaporator fan motor designed for HVAC applications, offering energy savings over traditional PSC and shaded pole designs. This 230 Volts, 0.70 Amps motor features ball bearings and a 42 NEMA frame, providing efficient air movement. It is suitable for replacing 1/15, 1/20, and 1/25 HP motors in various systems, including Heatcraft, InterLink, Bohn, Chandler, Climate Control, and Larkin units.

• Replaces InterLink 25317701S, featuring an Energy Savings ECM Design.
• Equipped with Ball Bearings, 60 Hertz operation, and Class B Insulation.
• Designed with four mounting studs on each end and includes a cord with a Lyall plug.

Product Highlights

Energy-efficient ECM evaporator fan motor with broad compatibility for HVAC systems.

Product Information

Standard Information

• Brand: DIVERSITECH
• Manufacturer Part Number: 97701
• Country of Origin: USA

Technical Specifications

• Brand: Diversitech
• Model: 97701
• Manufacturer: DiversiTech
• Included Components: Motor
• Unit Count: 1.0 Count
• Input Voltage: 230 Volts
• Material: Metal, Plastic
• Current: 0.70 Amps
• Bearings Type: Ball
• Country of Origin: USA
• Enclosure Type: TEAO
• Horsepower: 1/15-1/20-1/25 HP
• Frequency: 60 Hz
• Included Accessories: Lyall plug
• Insulation Class: B
• Motor Rotation: CWSE
• Motor Type: ECM
• Mounting Type: Stud
• NEMA Frame Size: 42
• RPM: 1625
• Number of Speeds: 1
