Diversitech 7-CRNR60 Time Delay, 60 Amp 250V Dual Element Fuse ECNR60

Product Description

The Diversitech 7-CRNR60 is a 60 Amp, dual-element time delay fuse designed for overcurrent protection in HVAC and industrial motor circuits. Classified under UL Class RK5, it provides delayed response to momentary inrush currents while offering rapid fault clearing under high short-circuit conditions. Its interrupt rating is 200,000 A at 250 VAC.

• Provides time delay for temporary over-current conditions and motor running protection for heating and air conditioning equipment.
• Eliminates unnecessary maintenance from harmless overloads.
• Dual-Element Design ��� Supports sustained motor startup currents without opening under normal overload conditions.

Product Highlights

This dual element fuse is suitable for high fault current applications across commercial and mechanical systems. It prevents nuisance openings during motor starts and other temporary overloads.

Product Information

Standard Information

• Brand: DIVERSITECH
• Manufacturer Part Number: 7-CRNR60
• Country of Origin: US

Technical Specifications

• Type: Time Delay
• Voltage: 250 VAC
• Amperage: 60 A
• Class: Class RK5
• Element: Dual
• Certifications: UL 198E
• Interrupt Rating: 200,000 A
• Country of Origin: US
• Item Type: Fuse
• Brand: DiversiTech
• Manufacturer: DiversiTech Corporation
• MPN: 7-CRNR60
• Length (inches): 0.75
• Width (inches): 0.75
• Height (inches): 3
• Sub Brand: Bullet��
• Size: 13/16 inch dia. x 3 inch L
• Connection: Ferrule
• Pressure Class: RK5
• Time Delay: 10 sec. (At 500 Percent Rated Load)
• Standards: UL Listed, CSA C22.2
• Application: For Motor Circuits, Branch Circuits, General-Purpose Protection
• Amps: 60
• Style: Time Delay
• Material: Copper
• Mounting Type: Through-Hole Mount
• Product Type: Time Delay
• Volts: 250
• Primary Depth (inches): 0.75
• Primary Width (inches): 0.75
• Primary Height (inches): 3
