Diversitech 7-CRNR20 Dual Element Time Delay Fuse, 250V, 20 Amp

Product Description

The Diversitech 7-CRNR20 dual element time delay fuse operates at 250V and 20 Amp. It provides time delay for temporary over-current conditions and motor running protection for heating and air conditioning equipment. This fuse eliminates unnecessary maintenance from harmless overloads and is a UL Class RK-5 fuse.

• Dual Element
• Time Delay
• 250V, 20 Amp

Product Highlights

Dual element time delay fuse with a voltage of 250V and a current rating of 20 Amp. Provides motor running protection.

Product Information

Standard Information

• Brand: DIVERSITECH
• Manufacturer Part Number: 7-CRNR20
• Country of Origin: United States

Technical Specifications

• Manufacturer: Diversitech Cor.
• Brand: Diversitech
• Item Model Number: 7-CRNR20
• Voltage: 250 V
• Amperage: 20 A
• Interrupt Rating: 200kA RMS AC
• Fuse Type: Dual Element Cartridge
• Type: Time Delay
• Fuse Class: rk-5
• Standards: UL Listed
• Element: Dual
• Voltage Rating: 250 VAC
• Amperage Rating: 20A
• Class: Class RK-5
• Additional Information: Overall Dimension 0.5 Inch Width x 2 Inch Depth x 0.5 Inch Height; Application Over-Current Condition, Heating and Air Conditioning Equipment, Harmless Overload
• Characteristics: Time Delay, Current Limiting
• Current Rating: 20 Amp
• Product Features: Provides Time Delay for Temporary Over-Current Conditions and Motor Running Protection for Heating and Air Conditioning Equipment; Eliminates Unnecessary Maintenance from Harmless Overload; Current Limiting Fuses
• MFR Part No: 7-CRNR20
• Time Delay: 8 sec. (At 500 Percent Rated Load)
• Connection: Ferrule
• Certifications: UL 198E
