Diversitech 626-hasr25 Time Delay Fuse 600V 25A

Product Description

The DIVERSITECH 626-hasr25 is a time delay fuse rated for 600 volts and 25 amps, designed to provide overcurrent protection in electrical circuits where brief inrush currents are expected at startup. Time delay fuses tolerate short-duration current surges — such as those produced by motor loads and compressors — without nuisance tripping, while still interrupting sustained fault currents quickly. This fuse is suited for HVAC equipment, commercial refrigeration controls, and general electrical distribution panels where reliable overcurrent protection is required.

This fuse is commonly installed in residential and light commercial HVAC systems, motor control circuits, and electrical disconnect boxes where time delay characteristics are necessary to accommodate compressor or fan motor startup loads. It is appropriate for any application requiring a 600-volt, 25-amp time delay fuse in a standard cartridge format. Licensed electricians and HVAC technicians are the typical installers for this type of overcurrent protection device.

Key Features

• Time delay design tolerates motor inrush currents without nuisance tripping
• Rated at 600 volts for use in high-voltage electrical circuits
• 25-amp current rating suitable for compressor and motor loads
• Provides reliable overcurrent and short-circuit protection

Compatibility

Designed as an OEM-style replacement time delay fuse for residential and light commercial HVAC disconnect boxes, motor control panels, and electrical distribution equipment requiring a 600-volt, 25-amp time delay cartridge fuse.

Installation Notes

Installation should be performed by a licensed electrician or qualified HVAC technician in accordance with the National Electrical Code (NEC). Always de-energize and lock out the circuit before removing or installing the fuse. Use an appropriately rated fuse puller for cartridge fuse removal. Verify that the replacement fuse matches the voltage and amperage ratings of the original before energizing the circuit.

Technical Specifications

• Fuse Type: Time Delay
• Voltage Rating: 600 volts
• Amperage Rating: 25 amps
• UPC: 0079458170726

Standard Information

• Brand: DIVERSITECH
• Manufacturer Part Number: 626-hasr25
