DIVERSITECH 5247 Motor Run Capacitor

Product Description

The DIVERSITECH 5247 is a heavy-duty motor run capacitor designed for continuous use. It utilizes self-clearing metalized polypropylene film technology, enhancing reliability and performance. This capacitor features a UL-approved pressure-sensitive interrupter and uses an eco-friendly oil for effective heat transfer and corrosion protection.

• Capacitance of 15 microfarads
• Voltage rating of 440 VAC
• Frequency rating of 50/60 Hz

Product Highlights

Ideal for heavy-duty applications, this capacitor ensures efficient operation and safety.

Product Information

Standard Information

• Capacitance: 15 uF
• Voltage Rating: 440 VAC

Technical Specifications

• Frequency Rating: 50/60 Hz
• Case Material: Aluminum
• Cover Material: Steel
• Dimensions: 2-11/16 inches H x 2 inches W x 1-1/4 inches D
• Country of Origin: US
• Shape: Oval
• Operating Temperature: -40 to 70 degrees Celsius
• Terminal Type: 1/4 inch Male Quick-Connect
• Type: Single Heavy Duty
• Case Height: 2-3/16 inches
