Diversitech 3GR0570 Round Motor Run Capacitor 70/5 Mfd 370 Vac

Product Description

Diversitech 3GR0570 is a round motor run capacitor rated 70/5 microfarad (Mfd) at 370 Vac for continuous motor and HVAC applications. The unit uses a hermetically sealed drawn steel case and is designed for motor run duty with oil-filled, non-PCB construction and 1/4-inch quick-connect terminals. It meets UL-810, CSA22.2 No190, and IEC60252 standards and has a rated life of 10,000 hours.

• Dual capacitance: 70 + 5 Mfd at 370 Vac for compressor and fan motor circuits
• Hermetically sealed drawn steel case, oil-filled (non-PCB) with 1/4-inch quick-connect terminals
• Meets UL-810, CSA22.2 No190, IEC60252 standards; rated life 10,000 hours

Product Highlights

Dual 70+5 Mfd, 370 Vac round motor run capacitor with oil fill and quick-connect terminals

Product Information

Standard Information

• Brand: DIVERSITECH
• Manufacturer Part Number: 3GR0570
• Country of Origin: Pakistan

Technical Specifications

• Brand: Diversitech
• Manufacturer Part Number: 3GR0570
• Type: Motor run capacitor (dual)
• Capacitance: 70 + 5 uF
• Voltage Rating: 370 Vac
• Case Material: Hermetically sealed drawn steel case
• Fill: Oil filled (non-PCB)
• Terminal Type: 1/4-inch quick-connect
• Standards / Certifications: UL-810; CSA22.2 No190; IEC60252
• Rated Life: 10,000 hours (manufacturer claim; see notes)
• Shape: Round
• Frequency: 50/60 Hz
• Tolerance: +/-5%
• Country of Origin: Pakistan
• Applications: HVAC systems, furnace blower motors, condenser fan motors, motor run applications
• UPC / EAN: 095247127566
