Diversitech 3GR0550 Motor Run Capacitor 370 VAC (Round/1 Pack) 0278-5152

DIVERSITECH
Brand: DIVERSITECH
SKU: 3GR0550
Availability: Out Of Stock
$21.41
$21.41
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The DiversiTech 3GR0550 is a dual-capacitance motor run capacitor (50+5 uF) rated at 370 VAC for continuous-run HVAC and motor applications. It features a round metal housing, rated frequency of 50/60 Hz, and a permissible temperature range of -40 C to +70 C. The unit meets UL-810, CSA 22.2 No. 190, and IEC60252 standards and is specified with a guaranteed life of 10,000 hours and 94% operating life at 60,000 hours.

  • Dual capacitance: 50+5 uF at 370 VAC, 50/60 Hz
  • Round metal housing for continuous run; operating temperature -40 C to +70 C
  • Meets UL-810, CSA 22.2 No. 190, IEC60252; guaranteed 10,000 hours life

Product Highlights

Dual 50+5 uF, 370 VAC motor run capacitor in a round metal can for continuous HVAC and motor applications; complies with UL-810, CSA, and IEC standards.

Product Information

Standard Information

  • Brand: DIVERSITECH
  • Manufacturer Part Number: 3GR0550
  • Country of Origin: China
Technical Specifications
Brand
DiversiTech
MPN
3GR0550
UPC
095247084654
Capacitance
50 + 5 uF (dual)
Voltage Rating
370 VAC
Frequency
50/60 Hz
Tolerance
+/- 5%
Type
Motor run capacitor (HVAC capacitor)
Intended Use
Continuous run motor applications (furnace blower, condenser fan motors)
Case Material
Metal
Shape
Round
Dimensions
Height 4.50 in x Diameter 2.25 in
Height
4.50 Inches
Diameter
2.25 Inches
Weight
0.60 - 0.68 Pounds
Terminals
1/4 in quick connect
Filling
Oil filled, non-PCB
Operating Temperature Range
-40 C to +70 C
Operating Life Guarantee
Guaranteed 10,000 hours under normal operating conditions
Operating Life (60,000 hours)
94% operating life at 60,000 hours
Standards / Certifications
UL-810; CSA 22.2 No. 190; IEC60252
Withstand Test Between Terminals
Rated voltage x 1.75, 10 sec
Withstand Test Between Terminals And Case
Rated voltage x 2 + 1000 V, 60 sec
Maximum Permissible Voltage
110% of rated voltage
Maximum Permissible Current
130% of rated current
Pack Quantity
1
Country of Origin
China
Datasheet
https://media.cityelectricsupply.com/media/diversitech/3gr0550/documents/diversite_datasheet_1039192.pdf
Product Brochure
https://media.cityelectricsupply.com/media/diversitech/3gr0550/documents/diversite_brochure_1039192.pdf
MPN/Stock Code (reference)
Stock Code 0278-5152
