Diversitech 25-90372 GENERAL PURPOSE RELAY (SPDT) 120VAC, (14/84@125V FLA/LRA, 8/48@250V FLA/LRA)

Product Description

The Diversitech D90-372 General Purpose Relay with MPN 25-90372 is designed for reliable switching in HVAC applications. This relay features single pole, double throw (SPDT) functionality with a coil voltage of 120VAC. It supports full load amps of 14 at 125 volts and 8 at 250 volts, making it suitable for various electrical systems.

• Quick connect terminals for easy installation
• Universal mounting with breakaway tabs
• Durable construction for long-lasting performance

Product Highlights

The relay provides efficient operation across different electrical loads and is ideal for air conditioning and heating units.

Product Information

Standard Information

• Brand: Diversitech
• MPN: 25-90372

Technical Specifications

• Type: General Purpose Relay
• Coil Voltage: 120VAC
• Full Load Amps (FLA): 14 @ 125V, 8 @ 250V
• Coil Resistance: 2000 ohms
• Mounting Type: Universal with breakaway tabs
