Diode Led DI-MLV-24V60W Magnetic Low Voltage (MLV) Dimmable Driver 60W (Each)

Product Description

Diode LED DI-MLV-24V60W is a magnetic low-voltage (MLV) dimmable driver that provides a 24 V output and 60 W power capacity. It supplies constant-voltage 24 V DC power for low-voltage tape lights and similar fixtures and supports up to 5 A output. The driver is compatible with many dimmers and on/off switches, housed in a metal enclosure rated NEMA 3R, and operates from -4 to 158 deg F with compact dimensions.

• Magnetic low-voltage (MLV) dimmable driver with 24 V DC constant-voltage output and 60 W power rating (5 A).
• NEMA 3R metal enclosure for indoor and outdoor use; cETLus listed and Class 2 power supply.
• Compact dimensions (6.8 in x 3.1 in x 2.9 in) and operating temperature range -4 to 158 deg F; compatible with many dimmers and Diode LED tape light applications.

Product Highlights

24 V DC constant-voltage output, 60 W (5 A) capacity, MLV dimming compatibility, NEMA 3R metal enclosure

Product Information

Standard Information

• Brand: DIODE LED
• Manufacturer Part Number: DI-MLV-24V60W
• Country of Origin: Mexico

Technical Specifications

• Manufacturer: Diode LED
• Brand: Diode LED
• MPN: DI-MLV-24V60W
• Catalog Number: DI-MLV-24V60W
• Series: MLV
• Type: Dimmable Driver
• Output Voltage: 24 V DC
• Power Rating: 60 W
• Output Current: 5 A
• Dimmable: Yes (MLV dimming compatible)
• Enclosure Rating: NEMA 3R
• Class: Class 2 Power Supply
• Certifications: cETLus listed
• Operating Temperature: -4 to 158 deg F
• Dimensions: 6.8 in x 3.1 in x 2.9 in
• Material: Metal
• Country of Origin: Mexico
• UPC: 848333030314
• Application: Compatible with many dimmers, on/off switches, Diode LED tape light
