Diode LED DI-0906 Constant Voltage LED Driver, 12V DC, 60W, Class 2

Product Description

The Diode LED DI-0906 is a constant voltage LED driver designed for efficient operation at twelve volts direct current. It provides a power output of sixty watts, making it suitable for a variety of low-voltage LED applications. This driver is especially designed for both indoor and outdoor use, operating in wet and dry environments.

• Input Voltage: 100 to 240 VAC
• Output Voltage: 12 VDC
• Power Rating: 60 W

Product Highlights

The DI-0906 LED driver ensures reliable performance with features that protect against common electrical faults.

Product Information

Standard Information

• Catalog Number: DI-0906
• Manufacturer: Diode LED

Technical Specifications

• Amperage Rating: 1.2/1 A
• Application: For low voltage LED tape light and fixtures, outdoor/Indoor and wet/dry locations
• Color: White
• Height: 1.26 inches
• Length: 6.4 inches
• Material: Plastic
• Mfg Standards/Approvals: CE Marked, CSA C22.2 NO 223-M91, cULus R/C 1310, UL Listed
• Output Voltage: 12 VDC
• Package Weight: 0.88 lb
• Temperature Rating: -22 to 158 degrees F
• Type: Hardwired Constant Voltage
• Width: 1.67 inches
