Dimplex 500005734 Revillusion 30 inches Built-In Electric Firebox with Herringbone Liner REVF30-HB

Product Description

The Dimplex 500005734 Revillusion 30" Built-In Electric Firebox with Herringbone Liner can be installed in a wall or pre-existing fireplace. It features larger, brighter, more random flames from within the Realogs. The firebox can be direct wired into 120V, 208V or 240V and operated manually or with the included remote. An optional 120V power supply cord is included for plug in use, but can be hardwired.

• 30" Built-In Electric Firebox with Herringbone Liner
• Can be installed right into a wall or into a pre-existing fireplace
• Larger, brighter, more random flames from within the Realogs

Product Highlights

The Revillusion firebox features life-like hardwood-cast logs, a reflective flame panel, and ThruView full-depth design. It includes an enhanced tumbled glass ember bed, mood-maker remote, and tempered front glass.

Product Information

Standard Information

• Brand: DIMPLEX
• Manufacturer Part Number: 500005734

Technical Specifications

• Installation Type: Built-In
• Nominal Fireplace Size (in.): 30
• Style: Traditional
• Fuel Type: Electric
• Blower: Included
• Heat Type: Flame Only / Heat On / Off
• Connectivity: Not WiFi Compatible
• BTUs: 4400 / 6745 / 8794
• Watts: 1375 / 1975 / 2575
• Depth (in.): 12.125
• Width (in.): 31.125
• Height (in.): 26.625
• Viewing Width (in.): NA
• Framing Depth (in.): 12.5
• Framing Width (in.): 30.625
• Framing Height (in.): 26.188
• Voltage: 120 / 208 / 240
• Amps: Varies
• Connection: Hardwire or Plug-In (Kit Included)
• Finish/Color: Herringbone
• Media Bed: Logs
• Model: REV30-HB
• Heat Location: Front Top Vents
• Remote Control: Multi-Function
• Power Connections: Plug-In/Hard-Wired
• Bulb Type: LED
• Flame Only Watts: 40
• Heating Area: 1000 sqft
• Vent Type: Vent-Free
• Zero-Clearance: Yes
• High Temp Setting: 99°F
• Low Temp Setting: 41°F
• No Heat Setting: Yes
• Adjustable Brightness: Yes
• Safety Agency Approval: Canada; USA
• Adjustable Flame: Yes
• Adjustable Flame Speed: Yes
• Supplemental Heat (sq. ft.): 1000 (based on 9 ft ceiling height)
• Dimensions: Width: 31.13", Height: 26.5", Depth: 12.13"
