Dimplex 500005140 Revillusion 42 inches Built-In Electric Firebox with Weathered Concrete Liner replacement RBF42-WCFG 500002411

Product Description

The DIMPLEX 500005140 Revillusion 42" Built-In Electric Firebox brings unused wood-burning fireplaces back to life and can be installed almost anywhere. This fully-recessed, built-in firebox features larger, brighter, more random flames from within the Realogs. It can be direct wired into 120V, 208V or 240V and operated manually or with the included multi-function remote.

• Revillusion 42" fully-recessed, built-in firebox
• Realogs are life-like hardwood-cast logs and sit tiered on a grate
• Can be direct wired into 120V, 208V or 240V, 15 amp dedicated circuit

Product Highlights

The Revillusion firebox features larger, brighter flames from within the Realogs. With Dimplex's ThruView Full-Depth Design, you can see right through the flames. It includes a weathered concrete liner, enhanced tumbled glass ember bed, and mood-maker remote.

Product Information

Standard Information

• Brand: DIMPLEX
• Manufacturer Part Number: 500005140

Technical Specifications

• Installation Type: Built-In
• Nominal Fireplace Size (in.): 42
• Style: Traditional
• Fuel Type: Electric
• Blower: Included
• Heat Type: Flame Only / Heat On / Off
• Connectivity: Not WiFi Compatible
• BTUs: 4400 / 6745 / 8794
• Watts: 1375 / 1975 / 2575
• Depth (in.): 12.125
• Width (in.): 43.25
• Height (in.): 31
• Viewing Width (in.): 31
• Framing Depth (in.): 12.5
• Framing Width (in.): 42.625
• Framing Height (in.): 30.625
• Voltage: 120 / 208 / 240
• Amps: Varies
• Connection: Hardwire Plug-In Kit (Kit Included)
• Brand: Dimplex
• Media Bed: Logs
• Model: REV42-WC
• Remote Control: Multi-Function
• Wiring: Direct Wire / Plug Kit
• Bulb Type: LED
• Flame Only Watts: 40
• Heating Area: Up to 1000 sqft
• Adjustable Brightness: Yes
• Power Connection: Plug-In/Hard-Wired
• Safety Agency Approval: Canada; USA
• Adjustable Flame: Yes
• Adjustable Flame Speed: Yes
• Supplemental Heat (sq. ft.): 1000 (based on 9 ft ceiling height)
• Finish/Color: Weathered Concrete
• Heat Location: Front Top Vents
