Product Description
The Dichtomatik OB3145059-BX is a precise oil seal designed for various applications. This NBR (BUNA) oil seal measures three point one two five inches in shaft diameter, four point five inches in outside diameter, and zero point five nine five inches in width. It is ideal for use in pumps, transmissions, gearboxes, and axles.
- Shaft diameter of three point one two five inches
- Outside diameter of four point five inches
- Width of zero point five nine five inches
Product Highlights
This oil seal offers strong resistance to oil and many petroleum-based hydraulic fluids, making it suitable for diverse industrial applications.
Product Information
Standard Information
-
Brand: Dichtomatik
-
Manufacturer: Dichtomatik
Technical Specifications
-
Shaft Diameter: 3.125 inches
-
Outside Diameter: 4.500 inches
-
Width: 0.595 inches
-
Material: NBR (BUNA)
-
Continuous Temperature Range: -40 to 200°F
-
Pressure Tolerance: Less than 10 psi
-
Typical Application: Pumps, Transmissions, Gearboxes, Axles
-
Seal Type: Cassette Seal
-
Number of Lips: 1
