Dial 7808 Square Corner Cooler Leg Kit Residential

Product Description

The DIAL 7808 is a square corner cooler leg kit designed to support and level residential evaporative coolers. The kit includes two 20-inch legs, two 30-inch legs, and four adjustable feet that compensate for uneven mounting surfaces. All legs are fabricated from 18-gauge steel for rigid, load-bearing durability. Fasteners are included for a complete installation. The tan and almond finish blends with standard residential cooler housings. This kit is used by HVAC technicians and qualified service professionals when replacing worn or damaged support legs or when setting up a new evaporative cooler installation.

The 7808 is suited for residential evaporative cooler applications where a stable, level base is required. The square corner leg design provides consistent contact with the cooler cabinet and the mounting surface. The adjustable feet allow the installer to fine-tune level without shimming, which is especially useful on rooftop or pad-mounted installations where surface irregularities are common. The included hardware means no additional fasteners are needed to complete the job.

Key Features

• Includes two 20-inch and two 30-inch square corner legs for full perimeter support
• 18-gauge steel construction provides rigid, long-term load bearing
• Four adjustable feet allow leveling on uneven surfaces without shimming
• All mounting fasteners included for a complete installation
• Tan and almond finish matches standard residential evaporative cooler cabinets

Compatibility

Designed as an OEM-style replacement leg kit for residential evaporative coolers requiring square corner leg support.

Installation Notes

Installation should be performed by a qualified HVAC technician or experienced service professional. Disconnect power to the evaporative cooler before beginning any structural service work. Use appropriate fasteners and ensure all four adjustable feet are firmly seated and the unit is confirmed level before restoring operation. Follow local mechanical codes for evaporative cooler mounting and support requirements.

Technical Specifications

• Leg Lengths: Two at 20 inches, two at 30 inches
• Material: 18-gauge steel
• Adjustable Feet: 4 included
• Finish Color: Tan and almond
• Fasteners Included: Yes

Standard Information

• Brand: DIAL
• Manufacturer Part Number: 7808
