Dewalt DW8270 Flap Disc 7in X 5/8in-11 Z40 T27 Xp

Product Description

The DEWALT DW8270 is a Type 27 (T27) flap disc designed for aggressive material removal on metal surfaces. It features a Z40-grit zirconia alumina abrasive, which delivers consistent cut rate and long service life under heavy grinding loads. At 7 inches in diameter with a 5/8 inches-11 threaded hub, this disc mounts directly to standard large-angle grinders. The flat T27 profile keeps the disc surface parallel to the workpiece, making it well suited for grinding flush to a surface or blending welds on flat stock. Fabricators, ironworkers, and metal tradespeople reach for this disc when they need material removed fast without repeated disc changes.

The DW8270 is intended for use on ferrous metals including structural steel, plate, pipe, and fabricated assemblies. The T27 geometry and Z40 grit make it a practical choice for weld blending, surface conditioning, and stock removal in both shop and field environments. It performs on flat or near-flat workpieces where a depressed-center profile would limit access. This disc is sold individually (UOM: Each) with a minimum order quantity of 5 units, making it appropriate for shop stocking or multi-tech supply orders.

Key Features

• Z40-grit zirconia alumina abrasive for aggressive stock removal and extended disc life
• Type 27 flat profile allows flush grinding and weld blending on flat surfaces
• 7 inches diameter with 5/8 inches-11 threaded hub fits standard large-angle grinders
• XP designation indicates extended performance abrasive construction for demanding applications
• Sold as individual units with a minimum order quantity of 5

Compatibility

Designed for use with large-angle grinders accepting a 7-inch disc diameter and a 5/8 inches-11 threaded spindle. No specific grinder model compatibility was provided in the product data.

Installation Notes

Installation should be performed by a qualified operator following the grinder manufacturer's mounting instructions and ANSI B7.1 safety standards for abrasive wheels. Confirm the grinder's maximum RPM rating meets or exceeds the disc's rated speed before mounting. Always inspect the disc for cracks or damage before use and never exceed the rated RPM. Wear appropriate PPE including a face shield, gloves, and hearing protection during operation.

Technical Specifications

• Disc Diameter: 7 inches
• Arbor Size: 5/8 inches-11 threaded hub
• Grit: Z40 (Zirconia Alumina)
• Disc Type: T27 (Type 27 Flat Profile)
• Unit of Measure: Each
• Minimum Order Quantity: 5
• UPC: 885911036788

Standard Information

• Brand: DEWALT
• Manufacturer Part Number: DW8270
