Dewalt DW4740 Diamond Tuck Point Blade (4-1/2 in x 0.250 in)

Product Description

The DeWalt DW4740 is a 4-1/2 in x 0.250 in diamond tuck point blade designed for tuck pointing and mortar removal on concrete, stone, and brick. It uses an extended performance diamond matrix (claimed 350x life) with large diamond cobalt segments and a segmented, laser-welded rim on a heat-treated steel body for durability. The blade is optimized for dry cutting with angle grinders and is rated to 13,300 RPM with a 5/8 in arbor.

• Extended performance diamond matrix with a claimed 350x life over conventional abrasives.
• Segmented, laser-welded rim and heat-treated steel body with large diamond cobalt segments for aggressive material removal.
• 4-1/2 in diameter x 0.250 in thickness, 5/8 in arbor, maximum 13,300 RPM; suitable for angle grinders and tuck pointing applications.

Product Highlights

4-1/2 in x 0.250 in XP segmented diamond tuck point blade; 5/8 in arbor; 13,300 RPM; dry cutting for concrete, stone, brick

Product Information

Standard Information

• Brand: DEWALT
• Manufacturer Part Number: DW4740
• Country of Origin: China

Technical Specifications

• Brand: DeWalt
• MPN: DW4740
• Product type: Diamond tuck point blade
• Model: XP tuck point blade
• Diameter: 4-1/2 in
• Thickness: 0.250 in
• Arbor Size: 5/8 in
• Maximum RPM: 13,300
• Blade Type: Segmented rim diamond blade
• Rim Type: Segmented, laser welded
• Body Material: Heat-treated steel
• Segment Composition: Large diamond segments with cobalt
• Matrix: Extended performance diamond matrix (claimed 350x life)
• Cutting Method: Dry cutting
• Suitable For: Angle grinders
• Applications: Tuck pointing, mortar removal, concrete, stone, brick
• Cutting Depth: 1-1/4 in
• Weight: 0.82 lb
• Compliance: California Proposition 65 (contains lead and lead compounds)
