Dewalt DCS714B Double Bevel Fixed Miter Saw 20V Max XR (10 in)

Product Description

DeWalt DCS714B is a 20V MAX XR 10-inch double bevel fixed miter saw (tool only) for executing miter and bevel cuts. It uses a 20V MAX XR brushless motor with regenerative braking and a bevel gear transmission to reduce power loss and extend runtime. The saw supports up to 6 in. horizontal cuts, 5-1/4 in. baseboard and crown nested capacity, provides adjustment-free cutline blade positioning, and captures up to 97% of dust.

• 20V MAX XR brushless motor with regenerative braking and bevel gear transmission to improve runtime
• 10 in. blade with up to 6 in. horizontal capacity and 5-1/4 in. baseboard/crown nested capacity; up to 434 cuts in 3-1/4 in. MDF and 311 cuts in 2x4 SPF using specified battery
• Adjustment-free cutline blade positioning, captures up to 97% of dust; Tool Connect Tag ready; tool only (battery and charger sold separately)

Product Highlights

10 in. dual-bevel miter saw with 20V MAX XR brushless motor, regenerative braking, bevel gear transmission, and up to 97% dust capture

Product Information

Standard Information

• Brand: DEWALT
• Manufacturer Part Number: DCS714B

Technical Specifications

• Brand: DEWALT
• MPN: DCS714B
• Product Type: Miter Saw
• Power Source: Battery / Cordless
• Input Voltage: 20V (maximum initial battery voltage 20V; nominal 18V)
• Motor: 20V MAX XR brushless motor
• Tool Only: Yes (battery and charger sold separately)
• Battery Compatibility: Compatible with DEWALT 20V MAX and DEWALT FlexVolt batteries (sold separately)
• Blade Diameter: 10 in
• Blade Teeth: 32T
• Cut Capacity Horizontal: Up to 6 in.
• Cut Capacity Vertical (Baseboard): 5-1/4 in.
• Crown Nested Capacity: 5-1/4 in.
• Cut Performance: Up to 434 cuts in 3-1/4 in. MDF base molding; up to 311 cuts in 2 in. x 4 in. SPF (using specified battery DCB2108)
• Dust Collection Efficiency: Captures up to 97% of dust
• Bevel Adjustments: 22.5° or 33.9° with included bevel pawls
• Cutline Positioning: Adjustment-free cut line indication with cutline blade positioning system
• Tool Connect: Tool Connect Tag ready (tag sold separately)
• Regenerative Braking: Yes
• Included Components: (1) 10 in. 32T Blade; (1) Stabilizer Bar; (1) Dust Bag; (1) Non-Airlock Vacuum Adapter; (1) Blade Wrench; (1) Material Clamp; (1) DCS714 saw
