Desco 19350 2 State LED Wrist Strap Touch Tester, 6VDC at 2.1 inches x 2.9 inches x 0.8 inches

Product Description

The Desco 19350 is a wrist strap tester used to ensure proper grounding for users in ESD-safe environments. This device acts as a common point ground for up to two wrist straps while also testing resistance levels. When the wearer touches the tester's metallic surface, a circuit is completed, lighting the green LED indicator if the resistance is between 750 kilohms and 10 megohms.

• Tests wrist straps and mat grounding
• Indicates resistance level with LED light
• Compact design for easy workstation use

Product Highlights

Quickly verify that wrist straps function correctly and ensure compliance with ESD standards.

Product Information

Standard Information

• Brand: Desco
• MPN: 19350

Technical Specifications

• Voltage Rating: 6VDC/4VDC Test
• Resistance Range: 750k - 10 Megaohm
• Dimensions: 2.1 inches (Width) x 2.9 inches (Height) x 0.8 inches (Depth)
• Accuracy: +/- 20%
• Power Supply: 120VAC Adapter
• Frequency Rating: 60 Hz
• Temperature Rating: 41 to 104 °F
• Weight: 0.1 lb
