Delta Faucet RP391-WH White Polypropylene Trip Lever Bath Waste Assembly

Product Description

The Delta Faucet RP391-WH is a white polypropylene bath waste assembly, designed with a trip lever mechanism for easy operation. Ideal for residential bathtub installations, this assembly is both ADA compliant and built to ASTM F409 standards.

• Corrosion-resistant materials including plated brass overflow plate
• Adjustable settings with vertical adjustment from 11 to 13-1/2 inches and horizontal adjustment from 6 to 7-3/4 inches
• Leak-proof performance offering less than one gallon per hour leakage at 6 inch water column

Product Highlights

This bath waste assembly incorporates a lift and drop gate mechanism operated by a lever mounted on the overflow plate, designed for durability and ease of maintenance. It's perfect for both new installations and repairs with parts that are easily accessible.

Product Information

Standard Information

• MPN: RP391-WH
• Brand: Delta Faucet
• Material: Polypropylene
• Finish: White
• Compliance: ADA, ICC/ANSI A117.1, ASTM F409

Technical Specifications

• Drain Hole Size: 1-5/8 inches
• Overflow Plate Size: 2-3/8 inches
• Vertical Adjustment Size: 11 to 13-1/2 inches
• Horizontal Adjustment Size: 6 to 7-3/4 inches
