Delta Faucet R3070-MIXLF Commercial Other: Cam Thermostatic Mixing Valve

Product Description

The Delta Faucet R3070-MIXLF is a thermostatic mixing valve designed for commercial applications. This valve is constructed with a forged brass body and features a compact size of three point seven five inches wide by four point two inches high.

• Outlet temperature range of ninety-five to one hundred twenty degrees Fahrenheit
• Automatic temperature control maintains consistent outlet temperature
• Built-in check valves prevent crossflow between hot and cold inlets

Product Highlights

The mixing valve is ideal for applications where stable water temperature is crucial. It is certified to CSA standards and is IAPMO listed for safety.

Product Information

Standard Information

• Brand: Delta Faucet
• MPN: R3070-MIXLF

Technical Specifications

• Body Material: Forged Brass
• Dimensions: Three point seven five inches wide by four point two inches high
• Domestic/Import: Import
• Maximum Working Pressure: 230 psi
• Minimum Flow Rate: 0.35 gpm
• Maximum Flow Rate: 5.8 gpm at forty-five psi
• Temperature Range: Ninety-five to one hundred twenty degrees Fahrenheit
• Regulating Piston Material: Engineered Polymer
