Delta Faucet 81T201BTA 1 FPT/Copper Soldered, 1-1/2 Top Spud, 1.6 GPF

Product Description

The Delta Faucet 81T201BTA is a battery-powered closet flush valve designed for commercial use. It features a diaphragm design with a top spud configuration for a seamless installation. This flush valve uses integrated sensor technology to detect use and provide efficient flushing with a flow rate of 1.6 gallons per flush.

• Diaphragm design with battery-powered sensor
• 1-1/2 inch spud size and 1 inch inlet size
• Renewable seat and vandal-resistant cover

Product Highlights

This product is ideal for high-traffic restrooms in commercial settings. The flush valve supports both right or left-hand supply installations and features an easy-to-maintain hinged battery housing.

Product Information

Standard Information

• Manufacturer: Delta Faucet
• UPC: 055870348141

Technical Specifications

• Actuation Type: Battery Powered Sensor
• Body Material: Forged Brass
• Flow Rate: 1.6 GPF
• Input Supply Rating: 6 Volt DC
• Body Configuration: Top Spud
• End Connection: Female Threaded/Copper Soldered
• Inlet Size: 1 Inch
• Spud Size: 1-1/2 Inch
• Applicable Standards: ADA, ICC/ANSI A117.1, CSA B125.3/ASSE 1037, IAPMO, UPC
• Finish: Polished Chrome
• Rough-In Size: 2.13 Inch
