Delavan 00110-60W1 Multi-Purpose Oil Burner Nozzle 1.10 60 Degree

Product Description

The DELAVAN 00110-60W1 Multi-Purpose Oil Burner Nozzle is a type W all-purpose nozzle that is neither truly hollow nor solid. These nozzles can be used in place of either solid or hollow cone nozzles between 0.40 and 8.00 GPH, regardless of the burner's air pattern. It features a brass body and a stainless-steel, hollow orifice. The lower flow rates tend to be more hollow.

• Type-W all purpose nozzles are neither truly hollow nor solid
• Can be used in place of either solid or hollow cone nozzles between 0.4 and 8 gph, regardless of the burner's air pattern
• Sintered filter for maximum protection

Product Highlights

Multi-purpose oil burner nozzle with precise spray angles, aerodynamic body, and a sintered filter for maximum protection.

Product Information

Standard Information

• Brand: DELAVAN
• Manufacturer Part Number: 00110-60W1

Technical Specifications

• Flow Rate: 1.1 GPH
• Manufacturer Name: Delavan
• Spray Angle: 60 Degree
• Spray Pattern: W, All Purpose
• Type: W, All Purpose
• Applicable Standard: ISO 9001
• Material: Brass Body, Steel Orifice Disc
• Pressure Rating: 100 PSI
• Temperature Rating: 80 Deg F
• Application: Residential
• Filter Type: Sintered
• Product Type: Burner Nozzles
• Pack Size: 1
• HVAC Product Type: Heating
• Product Depth (in.): 0.75
• Product Height (in.): 1.625
• Product Width (in.): 0.75
• UNSPSC: 40140000
