De-sta-co 210-USS Toggle Clamp Vertical 750 Lb U-bar

Product Description

The DE-STA-CO 210-USS is a manual hold-down toggle clamp designed for vertical clamping applications requiring a rated holding capacity of 750 pounds (3,340 N). Built entirely from stainless steel, including the handle and bar, this clamp is suited for environments where corrosion resistance and durability are priorities. The flanged base provides a stable four-hole mounting footprint, and the fixed-spindle U-bar design delivers repeatable, secure workpiece hold-down. The 3/8-16 threaded spindle offers 2.35 inches of travel, allowing adjustment to varied workpiece thicknesses. Licensed HVAC, welding, machining, and fixture professionals install this type of clamp in production jigs, welding fixtures, and assembly stations.

The 210-USS is appropriate for light industrial, manufacturing, and fabrication environments where a vertical-action toggle clamp with a flanged base is required. The straight red handle moves through 58 degrees of arc to lock and unlock, while the U-bar opens 103 degrees to allow easy workpiece loading and removal. The zinc-finish coating on hardware components complements the stainless steel body. Two flanged washers, two nuts, and the spindle are included, allowing installation without sourcing additional fasteners.

Key Features

• 750 lb (3,340 N) rated holding capacity for demanding fixture and jig applications
• Full stainless steel construction on bar, handle, and body for corrosion resistance
• 103-degree bar opening for wide, unobstructed workpiece access
• 58-degree handle movement for quick, positive lock and release
• 3/8-16 threaded spindle with 2.35 inches of travel for workpiece thickness adjustment
• Four-hole flanged base with 0.33-inch diameter mounting holes for rigid fixture mounting
• Includes flanged washers, nuts, and spindle - no additional hardware required

Compatibility

Designed as an OEM-style hold-down toggle clamp for use in vertical clamping fixtures, welding jigs, and assembly tooling requiring a flanged-base, U-bar clamp with a 3/8-16 spindle thread.

Installation Notes

Installation is performed by machinists, toolmakers, or fixture builders using standard hand tools. Mount the flanged base to a rigid surface through four holes sized for the included hardware before applying clamping load. Verify that the mounting surface and fasteners are rated to handle the full 750 lb holding capacity. Do not exceed the rated holding capacity or use the clamp as a structural member under dynamic or impact loading.
