De-sta-co 12/100 Clamp Plunger 100mm Stroke

Product Description

The DE-STA-CO 12/100 is a replacement clamp plunger designed for use in industrial toggle clamping applications. It features a plunger diameter of 12mm and a total plunger length of 8.98 inches (228.09mm), with a stroke length of 100mm to suit demanding workholding setups. The M6 thread size provides a secure, standardized connection point. Installation and replacement are typically handled by maintenance technicians and tooling specialists working with production fixtures and jigs. This plunger is built to maintain consistent clamping force and positioning accuracy in repetitive manufacturing environments.

This plunger is intended for use with DE-STA-CO Clamp Series FO, FL, and G toggle clamps. These clamp series are commonly found in welding fixtures, assembly jigs, and machining workholding applications across light and medium industrial settings. The 100mm stroke length makes this plunger suitable for setups requiring extended reach or deeper part engagement. Technicians working with existing FO, FL, or G series clamp bodies will find this a direct-fit replacement when the original plunger shows wear or thread damage.

Key Features

• 12mm plunger diameter for precise fitment within compatible clamp bodies
• 100mm stroke length provides extended reach in workholding fixtures
• Total plunger length of 8.98 inches (228.09mm) for consistent positioning
• M6 thread size offers a standardized, secure connection to the clamp assembly
• Compatible with multiple DE-STA-CO clamp series for broad fixture applicability

Compatibility

Designed for use with DE-STA-CO Clamp Series FO, FL, and G toggle clamps.

Installation Notes

Installation is typically performed by maintenance or tooling technicians familiar with toggle clamp assemblies. Before replacing the plunger, ensure the clamp is fully released and the fixture is de-energized or removed from the work cell. Use appropriately sized wrenches for the M6 thread to avoid stripping the connection. Follow the clamp manufacturer guidelines for proper plunger engagement depth and locknut torque to maintain consistent clamping performance.
