Dayton Lamina 16-18 Spring Cage 2 in Od Steel

Product Description

The DAYTON LAMINA 16-18 is a steel spring cage designed to retain and guide die springs in stamping and metalworking press tooling. The cage provides structural support around a coil spring, preventing lateral deflection under load and extending spring service life. With a 2-inch outside diameter and an overall length of 2.25 inches, this cage suits compact die sets where space is limited. Installation is performed by toolmakers and die maintenance technicians during press tool assembly or spring replacement service.

This spring cage is used in metal stamping dies, punch press tooling, and similar industrial die applications where spring retention and alignment are critical to consistent press performance. It is suited for both new die builds and maintenance replacement of worn or damaged cages in existing toolsets. The compact dimensions make it appropriate for smaller die stations with limited pocket depth.

Key Features

• Steel construction provides durability under repeated press cycle loading
• 2-inch outside diameter fits standard die spring pockets
• 2.25-inch overall length accommodates compact die station geometry
• Guides and retains coil springs to prevent lateral deflection under compression
• OEM-style replacement geometry for straightforward drop-in service

Compatibility

Designed as an OEM-style replacement spring cage for use with standard coil die springs in industrial stamping and punch press tooling applications.

Installation Notes

Spring cage installation and replacement is performed by qualified toolmakers or die maintenance technicians. De-energize and lock out the press completely before accessing the die set. Verify the cage outside diameter and overall length match the existing pocket and spring specifications before installation. Inspect the mating die plate pocket for wear or damage prior to fitting the replacement cage.
