Danfoss SZ185-4PCI Scroll Compressor 380-415/3/50 460/3/60 V/Ph/Hz

Product Description

The Danfoss SZ185-4PCI is a reliable scroll compressor ideal for air conditioning applications. It can use refrigerants including R404A, R407C, R134a, and R513A. The compressor operates with power supplies of 380-415/3/50 and 460/3/60 V/Ph/Hz. It features brazed connections and includes an electronic protection module. Shipped with suction and discharge solder sleeves, rotolock nuts, and gaskets, it is ready for efficient installation.

• Compatible with multiple refrigerants: R404A, R407C, R134a, and R513A
• Power supply options: 380-415/3/50 and 460/3/60 V/Ph/Hz
• Designed for air conditioning systems

Product Highlights

This compressor is designed for fixed-speed operation in air conditioning systems, ensuring consistent performance under various working conditions.

Product Information

Standard Information

• Brand: Danfoss
• MPN: SZ185-4PCI

Technical Specifications

• Model Number: SZ185W4PD
• Type: Scroll compressor
• Capacity Control: Fixed speed
• Compressor Power Supply: 380-415/3/50 and 460/3/60 V
• Frequency: 50/60 Hz
• Phase: 3
• Connection Type: Brazed
• Suction Connection Size: 1 5/8 inches
• Discharge Connection Size: 1 1/8 inches
• Oil Type: POE
• Oil Charge: 6.2 liters
• Motor Protection: Electronic protection module, 24 V AC
• IP Protection Class: IP54 (with cable gland)
• Approval: CE, UL, UKCA
• Swept Volume: 249.9 cm³
• Net Weight: 100 kilograms
• Gross Weight: 111 kilograms
• Refrigerant Charge: 13.5 kg
• Max Pressure (High Side): 34.3 bar
• Max Pressure (Low Side): 25 bar
• Rotational Speed at 50Hz: 2900 rpm
• Rotational Speed at 60Hz: 3500 rpm
• Diameter: 317 mm
• Total Height: 678 mm
