Danfoss 060-117391 KP5 SPDT pressure control (panel/din mount)

DANFOSS
Brand: DANFOSS
SKU: 060-117391
Availability: In Stock

Ships same day if ordered by 12 pm
$141.96
$141.96
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The Danfoss 060-117391 is a KP5 series SPDT pressure control designed for pressure monitoring and control in industrial, HVAC, hydraulic and pneumatic systems. It provides a pressure range of 5 to 445 PSI with a 10 amp contact rating at 240 VAC, panel or DIN-rail mounting and screw-terminal electrical connections. The unit is rated for operation from -40 to 185°F and is intended for harsh-environment applications.

  • SPDT contact configuration with 10 A contact rating at 240 VAC
  • Pressure range 5 to 445 PSI; suitable for industrial, HVAC, hydraulic and pneumatic systems
  • Panel or DIN-rail mounting with screw-terminal electrical connection; operating temperature -40 to 185°F

Product Highlights

KP5 SPDT pressure switch, 5–445 PSI range, 10 A @ 240 VAC contact rating, panel/DIN mounting, screw terminals, -40 to 185°F

Product Information

Standard Information

  • Brand: DANFOSS
  • Manufacturer Part Number: 060-117391
  • Country of Origin: China
Technical Specifications
Brand
Danfoss
MPN
060-117391
Model/Series
KP5
Product type
Pressure control / Pressure switch
Switch type
SPDT (single-pole, double-throw)
Pressure range
5 to 445 PSI
Differential
3 bar (43 psi)
Contact rating
10 amps at 240 VAC
Max working pressure
35 bar (510 psig)
Max test pressure
35 bar (510 psig)
Pressure connection type
Flare
Pressure connection size
1/4"
Pressure connection gender
Male
Pressure sensing element
Bellows
Mounting type
Panel mount or DIN rail
Electrical connection
Screw terminals
Electrical connection size
6-14 mm (referenced in documentation)
Enclosure rating
IP30 (NEMA 1)
Ambient temperature range
-40 to 185°F
Application notes
Not applicable for liquid line; suitable for refrigerant and industrial pressure control applications
Approvals / Certifications
BV, CCC, CE, DNV, GL, LR, LVD, RINA, RMRS, RoHS China, c UL us UL873, CS C22.2
Weight (net)
0.287 kg (listed in documentation)
EAN / GTIN
5702424497651
