Danfoss 034G7703 Electric Expansion Valve ETS 50C 1 1/8 in x 1 3/8 in

Product Description

The Danfoss 034G7703 Electric Expansion Valve ETS 50C is engineered for various refrigeration applications. This component functions effectively with multiple refrigerants like R134a and R22. It features a robust stainless steel body and is designed for efficient cooling performance.

• Inlet size: 1 1/8 inches, Outlet size: 1 3/8 inches
• Compatible with Danfoss controllers including EKE 1A, EKE 1B, and MCX 061V
• Enclosure rating of IP67 for protection against dust and water

Product Highlights

This expansion valve supports precise temperature control by adapting to various refrigerants, ensuring optimal performance.

Product Information

Standard Information

• Type: ETS 50C
• Product Group: Expansion valves

Technical Specifications

• Ambient Temperature Range Max: 70 °C
• Ambient Temperature Range Min: -40 °C
• Approval: ATEX, CE, EAC
• Max Working Pressure: 50 bar
• Inlet Connection Type: Solder ODF
• Outlet Connection Type: Solder ODF
• Motor Type: Bi-polar
• Electrical Connection Size: 4 pin M12
