Danfoss 018F6257 Solenoid Coil 12W (Multi Pack 24) 018F6257

Product Description

Danfoss 018F6257 is a BF024AS solenoid coil rated 24 V AC (50 Hz) with 12 W power consumption, designed for continuous duty and clip-on mounting. It features a 1 m three-core cable (3 x 0.75 mm2), actuator size 13.5 mm, and IP67 enclosure for dust and water protection. Class H coil winding insulation to IEC 85 and VDE 0580 design standard support use in refrigeration and EV series valve control applications.

• Rated input 24 V AC, 50 Hz; power consumption 20 VA (12 W) at 50 Hz
• Clip-on mounting with 1 m, 3-core cable (conductor area 3 x 0.75 mm2) and 6.6 mm cable diameter
• IP67 enclosure, Class H coil winding insulation (IEC 85), continuous duty

Product Highlights

BF024AS clip-on solenoid coil 24 V AC, 12 W, 1 m 3-core cable, IP67, multi pack (24)

Product Information

Standard Information

• Brand: DANFOSS
• Manufacturer Part Number: 018F6257
