Dali ebpt608010l-r-pc Bypass Shower Door 56-60x80 in

Product Description

The DALI ebpt608010l-r-pc is a semi-frameless bypass sliding shower door designed for alcove (3-wall) shower enclosures. It ships with a polished chrome frame and Riley handles, and uses 3/8-inch (10mm) low iron tempered glass with a factory-applied Nano clear coating for water, dirt, and stain resistance. Both panels slide in a full bypass configuration, allowing the door to be opened from either the left or right side. The unit adjusts up to 3/8 inch out-of-plumb on each side to achieve a watertight fit in imperfect alcove installations. A licensed contractor or experienced tile setter typically handles the final install.

This door fits alcove shower openings from 56 to 60 inches wide and 80 inches tall. The Riley handles span 20 inches center to center and double as towel bars, providing functional storage alongside the door. The polished chrome finish and low iron glass are suited to residential bathroom remodels where a clean, bright aesthetic is the goal. The full bypass design keeps both panels operable, which is practical in tighter bathroom layouts where a single-panel swing door is not feasible.

Key Features

• 3/8-inch (10mm) low iron tempered glass for clarity and impact resistance
• Factory-applied Nano clear coating resists water spots, dirt, and staining
• Full bypass design — both panels slide, openable from left or right
• Up to 3/8-inch out-of-plumb adjustability on each side for a watertight alcove fit
• Riley handles at 20-inch center-to-center spacing function as towel bars
• Polished chrome frame and hardware finish

Compatibility

Designed for alcove (3-wall) shower enclosures with rough openings between 56 and 60 inches wide and 80 inches tall.

Installation Notes

Power tools are not required for glass panel installation, but a level, drill, and silicone sealant are standard for plumb-wall alignment and watertight sealing at the sill and jambs. Shut off water supply to the shower area before beginning work. Follow local building codes for glass enclosure installations, including tempered glass requirements. Do not over-tighten hardware fasteners against the glass panels; follow the hardware torque guidance provided in the manufacturer installation sheet.

Technical Specifications

• Door Width Range: 56 to 60 inches
• Door Height: 80 inches
• Glass Thickness: 3/8 inch (10mm)
• Glass Type: Low iron tempered glass
• Glass Coating: Nano clear (water, dirt, and stain resistant)
• Frame Style: Semi-frameless
• Door Configuration: Full bypass, both panels slide
• Out-of-Plumb Adjustability: Up to 3/8 inch per side
• Handle Style: Riley
• Handle Spread: 20 inches center to center
• Hardware Finish: Polished chrome
• Enclosure Type: Alcove (3-wall)

Standard Information

• Brand: DALI
• Manufacturer Part Number: ebpt608010l-r-pc
