Dali ebpt608010l-j-pc Bypass Shower Door 56-60 in X 80 in

Product Description

The DALI ebpt608010l-j-pc is a semi-frameless bypass sliding shower door built for alcove (3-wall) shower enclosures. It features 3/8-inch (10mm) low iron tempered glass with a factory-applied Nano ClearCoat water-repellent and stain-resistant coating. The door frame and hardware are 304 stainless steel in a polished chrome finish. TruMotion soft-close technology controls the sliding panels so they close smoothly regardless of force applied. The full bypass design allows both panels to slide, and the unit provides up to 3/8 inch of out-of-plumb adjustability on each side for a watertight fit in out-of-square alcoves. Justin-style handles are included in polished chrome.

This door is designed for alcove shower installations with a rough opening width between 56 inches and 60 inches and a height of 80 inches. The walk-through clear opening ranges from 23.5 inches to 27.5 inches depending on panel position. The door opening height is 78 inches. Both sliding panels open from the left or right, making the unit adaptable to different bathroom layouts. The Justin handles are spaced 20 inches center to center and are sized to double as towel bars.

Key Features

• 3/8-inch low iron tempered glass with Nano ClearCoat water-repellent and stain-resistant coating
• TruMotion soft-close mechanism dampens panel movement regardless of closing force
• Full bypass design: both panels slide independently, opening from either side
• Up to 3/8-inch out-of-plumb adjustability per side for watertight fit in imperfect alcoves
• Justin handles in polished chrome double as towel bars, spaced 20 inches center to center
• 304 stainless steel frame and hardware construction for corrosion resistance

Compatibility

Designed for alcove (3-wall) shower enclosures with an opening width of 56 to 60 inches and a height of 80 inches, using a track-sliding bypass installation method.

Installation Notes

Installation is typically performed by a licensed tile contractor, plumber, or general contractor familiar with wet-area enclosure work. Shut off water supply and ensure the alcove substrate is fully cured and waterproofed before setting the track. Follow local building codes for glass enclosure anchoring and sealant requirements. Do not use abrasive tools or harsh chemicals on the low iron glass or Nano ClearCoat surface during or after installation.

Technical Specifications

• Minimum Width: 56 inches
• Maximum Width: 60 inches
• Height: 80 inches
• Door Opening Height: 78 inches
• Walk-Through Width: 23.5 inches to 27.5 inches
• Glass Thickness: 0.375 inches (10mm)
• Glass Style: Low Iron Tempered Glass
• Water-Repellent Coating: Nano ClearCoat Technology
• Door Opening Type: Bypass (both panels slide)
• Mounting Style: Track Sliding
• Installation Type: Alcove Shower
• Out-of-Plumb Adjustment: 3/8 inch per side
• Slow Close: TruMotion Technology
• Material: 304 Stainless Steel and Glass
• Hardware Finish: Polished Chrome
• Weight: 214 pounds

Standard Information

• Brand: DALI
• Manufacturer Part Number: ebpt608010l-j-pc
