Product Description
The Daikin GR9S800603BN is a gas furnace suitable for upflow or horizontal installation. This model operates on natural gas and features a single-stage gas valve. The furnace includes an aluminized-steel dual-diameter tubular heat exchanger and a multi-speed ECM blower motor for efficient operation. It also has a self-diagnostic control board to monitor the system's performance. The unit incorporates color-coded low-voltage terminals for easy accessory integration. The cabinet is coated with a baked-enamel finish for durability. This furnace is certified by AHRI and listed by ETL for quality assurance. It is designed for use across the United States, excluding California, and complies with R-32 standards.
- Features an aluminized-steel heat exchanger for effective heat transfer.
- Equipped with a multi-speed ECM motor to optimize airflow.
- Configured for upflow or horizontal installation for versatility.
Product Highlights
This furnace provides reliable and efficient heating for residential applications. It meets nationwide safety and efficiency standards.
Product Information
Standard Information
-
Brand: Daikin
-
Model Number: GR9S800603BN
Technical Specifications
-
Type: Gas Furnace
-
Product Line: GR9S80
-
Fuel Type: Natural Gas
-
Vent Type: Chimney Vent
-
Modulating/Staging: Single Stage
-
Blower Motor Type: ECM Multi-Speed
-
Configuration: Upflow/Horizontal
-
DOE Regional Compliance: Nationwide (Except CA)
-
AFUE: 80%
-
Heating BTU: 60000
-
High Fire Output: 48000 BTU
-
Maximum Air Flow: 1200 CFM
-
Voltage: 115 Volts
-
Minimum Circuit Ampacity: 7.7 Amps
-
Recommended Breaker Size: 15 Amps
-
Cabinet Width: 17.5 Inches
-
Product Height: 33.375 Inches
-
Product Width: 17.5 Inches
-
Product Depth: 28 Inches
-
Product Weight: 100 Pounds
