Daikin FXTQ54TAVJUA Vertical Air Handler

Product Description

The Daikin FXTQ54TAVJUA Vertical Air Handler is a versatile HVAC unit designed for various installation configurations, including up flow, horizontal-right, horizontal-left, and downflow. The downflow installation requires a field-installed downflow accessory kit.

• Variable speed ECM motor
• All-aluminum coil
• Optional slide-in electric heat up to 25 kW

Product Highlights

Ideal for residential HVAC systems, this air handler features an all-aluminum coil for greater efficiency and longevity. Its variable-speed ECM motor can handle nominal CFM up to 0.9 inches of external static pressure.

Product Information

Standard Information

• Brand: Daikin
• MPN: FXTQ54TAVJUA
• Part Number: DFXTQ54TAVJUA
• Item Number: 8102401

Technical Specifications

• Operation Modes: Cool, Dry, Auto, Heat, Fan
• Motor Type: Variable speed ECM
• Coil Material: All-aluminum
• Refrigerant Modulation: 2000 pulse electric expansion valve
• Air Leak Rate: Less than 2% (tested in accordance with ASHRAE 193)
• Auxiliary Heat Logic: Improved
• Electric Heat Option: Up to 25 kW
