DAIKIN AMST48CU1300 Air Handler

Product Description

The DAIKIN AMST48CU1300 air handler is built for indoor use and offers flexible mounting options. It utilizes an all-aluminum evaporator coil and is engineered for R-32 refrigerant. This unit features a factory-installed thermostatic expansion valve suitable for both cooling and heat pump settings.

• Multi-speed ECM blower motor enhances air flow control.
• Cabinet design supports both horizontal and vertical configurations.
• Factory-installed R-32 sensor monitors coil lifespan.

Product Highlights

This air handler provides efficient air circulation and is designed to minimize condensation.

Product Information

Standard Information

• Type: Air Handler
• Product Line: AMST

Technical Specifications

• Refrigerant Type: R-32
• Blower Motor Type: Multi-Speed
• Motor Type: ECM
• Mount Type: Multi-Position
• Installation Location: Indoor
• Electric Heat: Available
• Capacity: 4.0 Tons
• Cooling BTU: 48000
• Maximum Air Flow: 1820 CFM
• Minimum Air Flow: 1420 CFM
• Voltage: 208/230 Volts
• Phase: 1
• Frequency: 60 Hz
• Minimum Circuit Ampacity: 7.1 Amps
• Recommended Breaker Size: 15 Amps
• Suction Connection Size: 3/4 Inch
• Liquid Connection Size: 3/8 Inch
• Drain Outlet Diameter: 3/4 Inch
• Cabinet Width: 21 Inches
• Product Height: 58 Inches
• Product Width: 21 Inches
• Product Depth: 21 Inches
• Weight: 138 Pounds
• Shipping Weight: 153 Pounds
• ETL Listed: Yes
• AHRI Certified: Yes
• Parts Warranty: 10 Limited Years
• Model Number: AMST48CU1300
• Dimensions: 21-1/8 W x 21 D x 58 H
