Cutler-Hammer Manufacturing Co WBJ2200 2-Pole Circuit Breaker

Product Description

The Cutler-Hammer Manufacturing Co WBJ2200 is a 2-pole circuit breaker made for single-phase systems. Rated for 240 Volts AC and 200 Amperes, it is suitable for metering accessory applications. It features a thermal-magnetic trip and a lever actuator. This breaker has an interrupting capacity of 10,000 Amperes at sixty Hertz. Made from non-metallic material, it is UL Listed and operates efficiently at a temperature of forty degrees Celsius. The connection type for this unit is Bus to Lug. Dimensions include a height of six point two eight five inches, a length of two point nine nine seven inches, and a width of two inches.

• Rated at 200 Amperes for single-phase, 240 Volt AC systems.
• Features a 10,000 Ampere interrupting capacity.
• Utilizes a thermal magnetic trip type for circuit protection.

Product Highlights

Product Information

Standard Information

• Brand: Cutler-Hammer
• Connection: Bus to Lug

Technical Specifications

• Actuator: Lever
• Application: Metering Accessory
• Amperage Rating: 200 Amperes
• Frequency Rating: 60 Hertz
• Interrupt Rating: 10,000 Amperes
• Material: Non Metallic
• Phase: 1 Phase
• Number Of Poles: 2
• Operating Temperature: 40 Degrees Celsius
• Trip Type: Thermal Magnetic
• Voltage Rating: 240 Volts AC
• Height: 6.285 Inches
• Length: 2.997 Inches
• Width: 2.0 Inches
