Cutler-Hammer Manufacturing Co. FAZ-C3/1-NA-SP ETN FAZ-C3/1-NA-SP 1P 3A C C

Product Description

The Cutler-Hammer Manufacturing Co. FAZ-C3/1-NA-SP is a miniature circuit breaker designed for industrial applications. This UL 489 Industrial miniature circuit breaker acts as a supplementary protector with a single-pole configuration and a current rating of three amps. It can handle inrush currents and offers robust protection with an interrupt rating of 10 kAIC. The device operates at a voltage of 277 volts and is suitable for various applications.

• Single-pole design with a rating of three amps
• Interrupt rating of 10 kAIC for reliable circuit protection
• Compatible with DIN rail mounting for easy installation

Product Highlights

This circuit breaker is ideal for convenience receptacle circuits, motor control circuits, and PLC I/O points. It features thermal magnetic trip technology that ensures safe operation under varied load conditions.

Product Information

Standard Information

• Brand: Cutler-Hammer Manufacturing Co.
• Type: Supplementary

Technical Specifications

• Voltage: 277/480 VAC, 48 VDC
• Amperage: 3 Amp
• Number of Poles: 1 Pole
• Mounting Type: DIN Rail
• Trip Type: C-Curve, Thermal Magnetic
• Applications: For convenience receptacle circuits, motor control circuits, load circuits leaving the equipment, HACR internal/external equipment, PLC I/O points, computers, power supplies, control instrumentation, relays, UPS, and power conditioners.
• Interrupt Rating: 10 kAIC
