Cutler-Hammer Manufacturing Co BAB2100 - 100 Amp 2-Pole Circuit Breaker

Product Description

The Cutler-Hammer Manufacturing Co BAB2100 is a reliable 100 Amp, 2-pole circuit breaker designed for panelboard applications. This circuit breaker provides thermal-magnetic protection suitable for 120/240 VAC systems. It features a bolt-on connection for secure mounting. The product meets UL 489 standards, is CSA approved, and UL listed. It is rated for switching duty in 120 VAC fluorescent light applications and HACR rated for fifteen to one hundred amperes. The BAB2100 allows for flexible power feed connections and accommodates field mounting of accessories.

• Thermal-magnetic protection for electrical systems
• Connects easily to 120/240 VAC power systems
• Field mountable accessories for installation flexibility

Product Highlights

This circuit breaker is a key component for protecting electrical circuits in both residential and commercial settings.

Product Information

Standard Information

• Brand: Cutler-Hammer Manufacturing Co
• MPN: BAB2100

Technical Specifications

• Type: Type BAB
• Voltage Rating: 120/240 VAC
• Amperage Rating: 100 A
• Interrupt Rating: 10 kA
• Trip Type: Non-Interchangeable Thermal Magnetic
• Number of Poles: 2
• Phase: 1 ph
• Wire Size: 8 to 1/0 AWG
• Mounting Type: Bolted-On
• Dimensions: 3.8 in L x 2.3 in W x 4.8 in H
• Connection: Bolt-On
• Interrupting Capacity: 10,000/22,000 Amperes
• Item Model Number: CHBAB2100
• Part Number: BAB2100
• Batteries Required?: No
• Current Rating: 100 Amps
• Circuit Breaker Type: Standard
• Color: Black
• Product Dimensions: 5 x 10 x 8 inches
• Warranty Description: 1 year manufacturer
• Item Weight: 7.8 ounces
• Batteries Included?: No
• Item Package Quantity: 1
• Manufacturer: Cutler-Hammer
• Wattage: 250 watts
• Included Components: CHBAB2100
• UPC: 313096024004
• HACR Rated: Yes
• Standards: UL Listed and CSA Certified
