Cutler-Hammer HMCP050K2C Motor Circuit Protector 600 VAC, 250 VDC, 50 A, 3 Poles, Magnetic Trip

Product Description

The Cutler-Hammer Motor Circuit Protector, model HMCP050K2C, is designed for use in electrical systems with voltage ratings of up to six hundred volts AC and two hundred fifty volts DC. It provides reliable motor protection with a current rating of fifty amps and features three poles.

• Rated for 600 VAC and 250 VDC.
• Offers a magnetic trip type for effective circuit interruption.
• Part of the C Series, with a trip range from fifty to five hundred amps.

Product Highlights

This motor circuit protector is suitable for various commercial and industrial applications, serving both OEMs and electrical contractors.

Product Information

Standard Information

• Brand: Cutler-Hammer
• Manufacturer: Eaton

Technical Specifications

• Amperage Rating: 50 A
• Voltage Rating: 600 VAC, 250 VDC
• Number of Poles: 3
• Frame: F
• Series: C Series
• Dimensions: 3.38 in L x 4.13 in W x 6 in H
• Trip Type: Magnetic
• Trip Range: 50 to 500 A
