Cutler-Hammer HFD3125VL HFD 50(DG)C 125A 3P L

Product Description

The Cutler-Hammer HFD3125VL is a molded case circuit breaker designed for critical electrical distribution needs. This circuit breaker operates at a current rating of one hundred twenty-five amps with three poles, making it suitable for various applications in commercial settings. It provides reliable protection and control for electrical circuits with a voltage rating of six hundred volts AC and two hundred fifty volts DC.

• Molded case design ensuring durability.
• Fixed thermal and magnetic trip settings for enhanced safety.
• Wide frequency compatibility, operating at fifty and sixty hertz.

Product Highlights

This circuit breaker is ideal for those needing a robust solution for circuit protection. With a high interrupt rating, it is versatile for different electrical load demands.

Product Information

Standard Information

• Manufacturer: Cutler-Hammer
• Model Number: HFD3125VL

Technical Specifications

• Type: Molded case circuit breaker
• Frame: F
• Weight: 4.5 lbs
• Trip Type: Fixed thermal; fixed magnetic
• Dimensions: three point three eight inches x four point one three inches x four point one three inches
• Current Rating: 125 A
• Voltage Rating: 600 Vac; 250 Vdc
• Number of Poles: Three-pole
• Frequency Rating: 50/60 Hz
• Interrupt Rating 240VAC: 100 kAIC at 240 Vac; 65 kAIC at 480 Vac
• Standard: UL Listed
