Cutler-Hammer GHB2015 15A 2P CB

Product Description

The Cutler-Hammer GHB2015 is a molded case circuit breaker with a two-pole configuration and a current rating of fifteen Amps. This device is designed for use in various applications, including panelboards and switchboards, ensuring reliable circuit protection. It operates at 480Y/277 Vac and is suitable for both AC and DC circuits.

• Two-pole design for reliable branch circuit protection
• Fixed thermal and magnetic trip types for enhanced safety
• UL listed and compliant with federal specifications

Product Highlights

Designed for dependable performance, the GHB2015 is ideal for electrical assemblies and OEM applications. It has been tested for over twenty years, meeting North American safety standards.

Product Information

Standard Information

• Brand: Cutler-Hammer
• Manufacturer: Eaton

Technical Specifications

• Current Rating: 15 A
• Voltage Rating: 480Y/277 Vac; 125/250 Vdc
• Frequency Rating: 50/60 Hz
• Number Of Poles: Two-pole
• Dimensions: 3.8 inches L x 1.8 inches W x 4.8 inches H
• Interrupt Rating: 14 kAIC
• Trip Type: Fixed thermal; fixed magnetic
• Enclosure Type: NEMA 4
• Standard & Approvals: CSA Certified; Federal Specifications W-C375B; UL Listed
