Cutler-Hammer GHB1050 C Series Type GHB Molded Case Circuit Breaker, 277 VAC, 125 VDC, 50 A, 14 kA Interrupt, 1 Poles, Thermal Magnetic/Non-Interchangeable Trip

Product Description

The Cutler-Hammer GHB1050 is a molded case circuit breaker designed for reliable branch circuit protection in various applications like panel boards, switchboards, and motor control centers. This circuit breaker operates at 277 VAC and 125 VDC with a maximum current rating of 50 A, featuring a 14 kA interrupt rating. It meets high North American standards and is suitable for systems up to 600 VAC or 250 VDC.

• Voltage Rating: 277 VAC, 125 VDC
• Current Rating: 50 A
• Interrupt Rating: 14 kA

Product Highlights

This circuit breaker features a thermal magnetic trip mechanism and is designed for bolted-on mounting. Its compact dimensions are six point one inches in length, three point six inches in width, and two inches in height. It also has an operational frequency of fifty to sixty hertz, with a temperature rating of forty degrees Celsius.

Product Information

Standard Information

• Brand: Cutler-Hammer
• Manufacturer: Eaton

Technical Specifications

• Type: Type GHB
• Frame: G Series
• Mounting Type: Bolted-On
• Number of Poles: 1
• Trip Type: Thermal Magnetic/Non-Interchangeable
• Dimensions: 6.1 in L x 3.6 in W x 2 in H
• Frequency Rating: 50/60 Hz
• Temperature Rating: 40 deg C
