Cutler-Hammer GHB1030 Molded Case Circuit Breaker 30A 277 Vac 125 Vdc

Product Description

The Cutler-Hammer GHB1030 is a molded case circuit breaker with a current rating of thirty amps. This breaker is suitable for applications where reliable circuit protection is required. It is designed for use in panelboards, switchboards, motor control centers, and busway systems.

• 30A current rating
• Single-pole design
• Rated for 277 Vac and 125 Vdc

Product Highlights

The GHB1030 features fixed thermal and magnetic trip types for consistent performance and safety. It meets various North American standards for safety and reliability.

Product Information

Standard Information

• Type: Molded case circuit breaker
• Manufacturer: Cutler-Hammer

Technical Specifications

• Height: 4 inches
• Length: 2.63 inches
• Width: 1 inch
• Weight: 0.65 pounds
• Amperage Rating: 30A
• Interrupt Rating: 14 kAIC at 277 Vac
• Number of Poles: Single-pole
• Voltage Rating: 277 Vac, 125 Vdc
• Trip Type: Fixed thermal, fixed magnetic
• Circuit Breaker Type: GHB
• Circuit Breaker Frame Type: Complete breaker
• Frame Size: G-frame
• Series: Series C
• Frequency Rating: 50/60 Hz
