Cutler & Hammer FD3150VL Type FD Brkr 3P 150A

Product Description

The CUTLER & HAMMER FD3150VL is an Eaton Series C complete molded case circuit breaker with a fixed thermal and magnetic trip. This three-pole breaker is rated at 150A and is suitable for 600 Vac and 250 Vdc systems. It has a 65 kAIC at 240 Vac and 35 kAIC at 480 Vac interrupt rating and is designed for line and load connections, operating at 50/60 Hz.

• Eaton Series C
• Fixed thermal trip
• Fixed magnetic trip

Product Highlights

Molded case circuit breaker with fixed thermal and magnetic trip, suitable for various electrical systems.

Product Information

Standard Information

• Brand: CUTLER & HAMMER
• Manufacturer Part Number: FD3150VL

Technical Specifications

• Brand: CUTLER & HAMMER
• MPN: FD3150VL
• Type: FD
• Poles: Three-pole
• Amperage: 150A
• Voltage: 600 Vac; 250 Vdc
• kAIC: 65 kAIC at 240 Vac; 35 kAIC at 480 Vac
• Frame: F-frame
• Product Length/Depth: 3.38 in
• Product Height: 6 in
• Product Width: 4.13 in
• Certifications: UL Listed
• Product Type: Molded case circuit breaker
• Amperage Rating: 150 A
• Voltage rating: 600 Vac, 250 Vdc
• Trip Type: T186
• Circuit breaker type: FD
• Circuit breaker frame type: Complete breaker
• Series: Series C
• Terminals: Line and load
• Frequency rating: 50/60 Hz
• Calibration: 50°C
• Interrupt rating: 65 kAIC at 240 Vac 35 kAIC at 480 Vac
• Number of poles: Three-pole
• Current Rating: 150 A
• Max Voltage: 250 VDC, 600 VAC
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Mounting: Panel
• Approvals: UL
