Cutler-Hammer FD3150KL 3P 150A SW

Product Description

The Cutler-Hammer FD3150KL is a three-pole molded case switch rated at 150 amperes. This switch operates at a voltage of six hundred volts AC and two hundred fifty volts DC, suitable for various electrical applications. The unit features fixed thermal and fixed magnetic trip types, ensuring reliable performance in demanding conditions.

• Three-pole design for versatile connections
• Rated for 150A current and 600V AC, 250V DC
• Includes a fixed thermal and magnetic trip type

Product Highlights

This molded case switch from Cutler-Hammer offers robust protection for electrical circuits. Its design allows it to withstand high fault currents, making it a reliable choice for distribution systems.

Product Information

Standard Information

• Manufacturer: Cutler-Hammer
• Family Group: Distribution Equipment

Technical Specifications

• Type: Molded case switch
• Frame: F
• Weight: 4.35 lbs
• Voltage Rating: 600 Vac; 250 Vdc
• Current Rating: 150 A
• Number Of Poles: Three-pole
• Frequency Rating: 50/60 Hz
• Interrupt Rating 240VAC: 65 kAIC at 240 Vac; 35 kAIC at 480 Vac
• Dimensions: 3.3800 inches x 2.7500 inches x 6.0000 inches
