Cutler-Hammer FD1020 Molded Case Circuit Breaker 277 Vac 125 Vdc 20 A 1 Pole

Product Description

The Cutler-Hammer FD1020 is a molded case circuit breaker by Eaton. It is designed for applications requiring circuit protection at 277 VAC and 125 VDC with current ratings up to twenty amperes. Built with a series C design, this breaker is ideal for panelboards and motor control centers.

• Type FD, one pole circuit breaker
• Rated for 277 VAC and 125 VDC
• Includes instantaneous and long time trip settings

Product Highlights

This circuit breaker is HACR rated and suitable for use with high-intensity discharge (HID) lighting. Its F-frame design allows for reliable performance in a variety of applications.

Product Information

Standard Information

• Manufacturer: Eaton
• Model Number: FD1020

Technical Specifications

• Type: Molded Case Circuit Breaker
• Frame: F
• Phase: 1
• Trip Type: Instantaneous/Long Time
• Wire Size: 14 to 1/0 AWG
• Dimensions: 6 in H x 1-3/8 in W x 3-3/8 in D
• Enclosure Type: NEMA AB1/AB3
• Voltage Rating: 277 VAC, 125 VDC
• Amperage Rating: 20 A
• Connection Type: Load Lug
• Number of Poles: 1
• Frequency Rating: 50/60 Hz
• Interrupt Rating: 25 kA
• Temperature Rating: 40 deg C
