Eaton XTCE012B10T IEC Contactor 24VAC 12A Frame B Three-Pole Non-Reversing

Product Description

The Eaton XTCE012B10T IEC Contactor is engineered for robust and precise performance. Ideal for industrial automation, this 24VAC, 12-amp, three-pole contactor ensures reliable operation in demanding environments.

• Compact frame B design measuring 45mm width.
• Provides non-reversing contact configuration.
• Operates at a coil voltage of 24VAC with a frequency of 50-60Hz.

Product Highlights

Manufactured in Romania, the Eaton XTCE012B10T meets global standards. It is CE marked, CSA certified, IEC, UL listed, and RoHS compliant. An ideal solution for electrical assemblies and EOEMs, the contactor offers a clear functionality with its straightforward design. Its robust screw terminal connections and a wide operating temperature range (-13 to 122 degrees Fahrenheit) complement various industrial settings.

Product Information

Standard Information

• Brand: Eaton
• Series: XT Series

Technical Specifications

• Type: Full Voltage Non-Reversing
• Mounting Type: DIN Rail/Panel
• Enclosure: IP20
• Dimensions: 1.77 in W x 2.95 in D x 2.68 in H
• Standards/Approvals: CE Marking, CSA Certified, EN 60947, IEC 60947, RoHS Compliant, UL Listed
