Eaton C25BNB240A Definite Purpose Control Contactor 110-120 VAC 2 Pole

Product Description

The Eaton C25BNB240A is a definite purpose control contactor designed for HVAC applications. This compact, non-reversing contactor operates at 110-120 VAC and supports a maximum load current of 40/50 amperes. Designed for quick installation and maintenance, this model features binding head screw and quick-connect terminals.

• 110-120 VAC coil voltage
• 2-pole configuration
• Open enclosure with metal mounting plate

Product Highlights

This Eaton contactor is ideal for motor and power control equipment. With universal mounting plates and snap-on accessories, installation is hassle-free. It operates efficiently in temperatures ranging from -13 to 158 degrees Fahrenheit, making it suitable for diverse environments.

Technical Specifications

• Catalog Number: C25BNB240A
• Brand: Eaton
• Frame: Compact, Two-pole
• Width: 2.32 inches
• Height: 3.19 inches
• Length: 2.32 inches
• Weight: 0.568 lb
• Voltage: 110-120 Volt
• Amperage: 40/50 A
• Enclosure: Open with metal mounting plate
• UPC: 78668511607
• GTIN: 00786685116075
• Applications: Motor and Power Control Equipment
• Coil Voltage: 110-120 VAC at 50/60 Hz
• Connection Type: Quick-Connect
• Terminal Type: Binding Head Screw
• Number of Poles: 2
• Frequency Rating: 50/60 Hz
• Operating Temperature: -13 to 158 degrees Fahrenheit
• Standards/Approvals: RoHS Compliant, UL Recognized, CSA Certified
• Country of Origin: China
